Experience Pre-Certified, Personalized Connectivity

Telit Cinterion CMB100

Jari Haiston in Blogs on July 07, 2025

About Jari Haiston

Jari Haiston is part of the growing digital marketing team at Symmetry Electronics. Jari comes from a background in technical writing and event coordination. In her current role, she specializes in content creation and social media management. Jari's focus as a writer is to create interesting content that is accessible to any audience.
Available at Braemac Americas, discover how you can experience pre-certified, personalized connectivity with the Telit Cinterion CMB100

With 40 years of expertise as a global semiconductor component distributor and value-added services provider–Braemac Americas (rebranded from Symmetry Electronics) understands the complexities of end-device certification. Braemac is deeply familiar with the cost, risk, and time investment involved in developing LTE-enabled innovations. That is why Telit Cinterion’s CMB100 series stands out as a true game-changer in the world of cellular connectivity.

Developer-Friendly and Carrier-Approved

Designed to eliminate complexity, the CMB100 supports LTE Cat 4, Cat 1 bis, Cat M1, and RedCap 5G (launching September 2025), all within a single, future-ready platform. With a wide range of pre-approvals, it mitigates the need for costly redesigns and recertifications. The CMB100 enables scalable LTE and 5G-ready certification across a wide range of applications.

Ideal for developers looking to add cellular connectivity to industrial and commercial devices, the CMB100 comes equipped with a broad range of approvals, including FCC/IC, RED/GCF, PTCRB, Verizon, and AT&T.

CMB100 Key Features
  • Standard mini berg connector with 20 mm pitch
  • Best-in-class 3GPP Release (Rel) 10 platform
  • Easy to integrate with peripherals and actuators using USB 2.0 HS, UART and user-definable GPIOs
  • Wide power supply support range (1.8 V* to 5.5 V)
  • Battery-friendly 1.8 V GPIO
  • GPIO level translation for 3.3 V system
  • Ideal platform for IoT applications, mobile data and ultracompact computing devices with extended operating temperature range
  • Internet-friendly with integrated TCP/IP and UDP/IP stacks
  • Firmware over-the-air (FOTA) updates
  • FCC/IC and RED certified and device certified with major carriers
  • 2G and 3G fallback and GNSS for accurate location services

Achieve Purpose-Built Connectivity with CMB100 Rapid Development Kit

Designed to support 1500 unique mikro Click Boards™, the CMB100 Rapid Development Kit enables customized cellular connectivity that is virtually limitless. With the CMB100 Rapid Dev Kit, developers are empowered to quickly prototype a robust library of purpose-built solution baseboards for applications in:

  • Asset Tracking: Accel, GPS, Battery
  • Automotive: Accel, GPS, CAN/OBD
  • Gateway: LoRa®, Bluetooth®, Wi-Fi, Cellular
  • Environmental: Temperature, Humidity, Pressure
  • Sensor I/O: ADC, GPIO
  • Comm: Serial, 4-20mA, HART, Ethernet

Telit Cinterion is also planning to release the CMB100 Rapid DevKit v2 this year. The next-gen kit will include SMA connectors for antennas, an IMU and battery charger, expanded LEDs, a reset button, and optional Temp/Humidity, light, and IMU sensors.

CMB100 Rapid Dev Kit Key Features
  • MCU: STM32H5 with multiple comm ports
  • Serial: 1 modem host port, 1 debug, 3 to the mikroBUS expansion slots
  • 3x SPI, I2C connections to the mikroBUS expansion slots
  • Optional CAN XCVR, NOR Flash, IMU
  • GPIO mapped to CMB100

NExT™ Level Services

Telit Cinterion’s NExT™ Global Cellular Connectivity delivers global, secure, and cost-effective cellular connectivity and device management services. Engineered to simplify the management of connected ecosystems, NExT offers flexible plan options that ensure seamless roaming, robust security, and unmatched flexibility.

Telit Cinterion’s NExT™ Global Cellular Connectivity delivers global, secure, and cost-effective cellular connectivity and device management services.

Backed by multiple success stories from Telit Cinterion–customers like Elsight, Terradona, and Nordsense, utilize NExT to streamline connectivity management throughout their application’s entire lifecycle.

NExT users benefit from key features such as:

  • An enhanced IoT mobile broadband that includes access to Telit Cinterion’s MVNO services and extended global coverage on various SIM technologies.
  • A fully geo-redundant IP core network with AWS Cloud failover. 600+ carriers in 200+ countries.
  • Voice and data plans for the following technologies: 2G, 3G, 4G LTE, Cat M, NB-IoT, and 5G.

Synergizing CBM100 with NExT for Scalable Intelligence

As an entire ecosystem of connectivity management services, the NExT platform includes a broad range of tools to meet the needs of every project:

Turnkey Cellular Applications with CMB100 and NeXT

Not only does the CMB100 fully support Telit Cinterion’s comprehensive line of value-added services like zero-touch onboarding, edge logic control, and enterprise integration, but it pairs seamlessly with NExT Global Connectivity services.

By synergizing the CMB100 with NExT, developers gain a streamlined, pre-certified hardware platform supported by intelligent device management and secure, scalable services. Developers can leverage this turnkey combination to accelerate development, reduce complexity, and support global deployments from prototype to production.

Technical Resources
